Processing Characteristics | Consumer electronics supplier, welding, shipbuilding, iron and steel manufacturing plants based machining |
main customer | LG Electronics, SeAH ESAB, Woojin Steel, ohseongsa and others |
Category | Large Slitter(2Line) | Large Shear | Small Slitter |
---|---|---|---|
Capacity/year | 23,000ton | 40,000ton | 30,000ton |
Inside Diameter | 508 - 610mm | 508 - 610mm | 508mm |
Outside Diameter | 2,200mm(Max) | 1,800mm(Max) | 1,600mm(Max) |
Thickness | 0.30 - 3.20mm | 0.30 - 1.60mm | 0.30 - 2.30mm |
Width | 400 - 1,960mm | 100 - 1,000mm | 8 - 80mm |
Length | - | 200 - 3,000mm | - |
Max weight | 25ton | 15ton | 7.5ton |
LINE SPEED | 200M/Min | 80M/Min | 120M/Min |
